Indoor 2-Channel Radio Remote Control Kit – 433MHz

Indoor two-channel radio remote control kit operating in the 433 MHz band, suitable for automating gates, irrigation systems and lighting systems
Indoor 2-Channel Radio Remote Control Kit - 433MHz - Image 1
Indoor 2-Channel Radio Remote Control Kit - 433MHz - Image 3

SKU 8101-SUPRK001EAN 8054242080131Item type: Assembled

Description

Indoor two-channel radio remote control kit operating in the 433 MHz band, suitable for automating roller shutters, blinds, gates, irrigation systems and lighting systems. It has two separately configurable channels, in either monostable or bistable mode. A normally-open contact is provided for each of the two channels, while for the common contact both outputs share the same common COM terminal. Maximum compatibility with all brands operating at 433.92 MHz. Supplied complete with two fixed-code remote controls with self-learning programming.
Package contents
  • Antenna
  • Receiver
  • 2 remote controls

Technical details

Weight 170 g
Dimensions 10.5 x 7 x 3.5 cm
Receiver power supply 12V DC – 24V DC
Maximum relay load current 12A – 14 VDC / 7A 120 VAC
Frequency 433 MHz
Remote control batteries 12V (included)
Red wire 12/24V DC
Black wire GND
White wire COM contact
Green wire N.O. contact CH1
Yellow wire N.O. contact CH2
