Peltier Cell 51W 40×40 mm

Solid-state heat pump running on 12 V and drawing 6.4 A maximum, to cool or heat by direct contact.
Peltier Cell 51W 40x40 mm - Image 1

SKU 1560-5112EAN 8219671010054Item type: Assembled,

Description

51W PELTIER cell running on 12 volts. Maximum current draw 6.4 amps. Maximum differential between hot-side and cold-side temperatures 68 °C. Maximum supply voltage 14.9 volts. Maximum cooling power 51 watts with the hot-side temperature held at 27 °C. Weight 27 grams. Operating life: about 200,000 hours.

Technical characteristics

Hot-side temperature (°C)
25°C
50°C
Qmax (Watt)
50
57
Delta Tmax (°C)
66
75
Imax (Amp)
6.4
6.4
Vmax (Volt)
14.4
16.4
Resistance (Ohm)
1.98
2.30
