RF transceiver module WIZ-434-SML-IA5V

Transceiver module ideal for replacing a serial link with a half-duplex RF wireless connection [433.92 MHz band], with serial data rate selectable between 9600, 19200, 57600 and 115200 bps
RF transceiver module WIZ-434-SML-IA5V - Image 1

SKU 8110-WIZ-434IA5EAN 8219671028110Item type: Assembled

Description

Transceiver module ideal for replacing a serial link with a half-duplex RF wireless connection [433.92 MHz band], with serial data rate selectable between 9600, 19200, 57600 and 115200 bps. Maximum data packet length is 96 bytes. The antenna is built into the printed circuit board. For use with: WIZ-434-SML IA /12V. Logic: 0÷5 V, Consumption: 30 mA, Power supply: +5V, TX power: 3 mW, Bit rate: 9.6 ÷ 115.2 kbps, Dimensions: 37x93x20 mm. Aurel code: WIZ-434-SML IA /5V, 650200626).
