1D and 2D Barcode Reader Module

Description

Compact and high-performance module capable of reading linear barcodes (Code 39, UPC, EAN, Code93) and two-dimensional codes (QR Code, PDF417, Data Matrix). To use it, simply connect it to the PC’s USB port (by default it emulates a keyboard), open a text program (e.g., Word, WordPad, etc.), point the reader at the barcode, and the read code will be decoded and the result written into the open text program’s page.

Linear (1D)

• Code 39

• UPC

• EAN

• Code93


Two-Dimensional (2D)

• QR Code

• PDF417

• Data Matrix


Technical Specifications

• Barcode types it can read:
  – Linear (1D): Code 39 / UPC / EAN / Code93
  – Two-dimensional (2D): QR Code / PDF417 / Data Matrix
• Dimensions (mm): 50x28x14
• Weight: 10.5 grams
