DRIVER MODULE FOR DOT MATRIX DISPLAYS

Based on the PIC16F723 microcontroller, this board drives dot matrix displays (see related products)
DRIVER MODULE FOR DOT MATRIX DISPLAYS - Image 1

SKU 7719-DOTMATRIXLEDEAN 8219671030564Item type: Assembled

Description

Based on the PIC16F723 microcontroller, this board manages matrix displays (see related items). It features a mini-B USB connector for PC connection, two buttons for testing and setup, two connectors for daisy-chaining displays (up to 8 displays in series), and two screw terminals providing a 5V supply. Using the Sure-LEDV1.0 software, freely downloadable, you can display and scroll ASCII characters on the display and select the scroll speed. Power supply: 8 to 30 Vdc, dimensions (mm): 109.10 (length) x 81.10 (width) x 18 (height). The package includes the matrix display driver and 2 16-pin IDC cables.

Applications

Software Screenshot

Connections

Documentation and Useful Links
