PIC16F874A-I/P Microchip Flash microcontroller

Microchip PIC16F874A-I/P Flash microcontroller, 40 pins, 33 I/O ports, 4 K Flash program memory, clock: 20 MHz crystal, 2 PWM and 3 timers
PIC16F874A-I/P Microchip Flash microcontroller - Image 1

SKU 1340-PIC16F874A-I/PEAN 8219671068826Item type: Assembled

Description

PIC16F84 Microchip IC

Microchip PIC16F874A-I/P Flash microcontroller, 40 pins, 33 I/O ports, 4 K Flash program memory, clock: 20 MHz crystal, 2 PWM and 3 timers. Package: PDIP40.
 Technical specifications
  • 10-bit A/D converter: 8

Technical details

clock 20 MHz crystal, 2 PWM and 3 timers
Package PDIP40
Supply 2 to 5.5 Vdc
Input/Output ports 33
Flash program memory (14-bit words) 4 K
Data memory 192 bytes
EEprom Data Memory 128 bytes
Interrupts 15
Oscillator crystal, 20 MHz max
Number of instructions 35
Timers 3
Capture/Compare/PWM modules 2
Serial Communications MSSP, USART
Parallel Communications PSP
