PIC16F877-20/P Microchip microcontroller

PIC16F877-20/P Microchip Flash microcontroller, 40-pin dual in line - 33 Input/Output ports - 8k Flash program memory.
PIC16F877-20/P Microchip microcontroller - Image 1

SKU 1340-PIC16F877-20/PEAN 8219671001236Item type: Assembled

Description

PIC16F877 Microchip IC
PIC16F877-20/P Microchip Flash microcontroller, 40-pin dual in line – 33 Input/Output ports – 8k Flash program memory.
 TECHNICAL SPECIFICATIONS
▪ Plastic dual in line 40-pin package
▪ Supply voltage from 3 to 5.5Vdc
▪ Current draw < 0.6mA at 3Vdc
▪ 33 Input/Output ports
▪ Flash program memory 8K
▪ RAM 368
▪ EEPROM data memory: 256
▪ Interrupt sources: 14
▪ Oscillator: crystal, max. 20MHz
▪ In-circuit serial programming
▪ Number of instructions: 35
▪ 8 A/D converters, 10-bit
▪ 3 timers
▪ 2 Capture/Compare/PWM modules
▪ Serial communications: MSSP, USART
▪ Parallel communications: PSP
