PIC18F1220-I/P Microchip microcontroller

Microchip Flash microcontroller, 18-pin DIP, 16 I/O ports - 4K Flash program memory.
PIC18F1220-I/P Microchip microcontroller - Image 1

SKU 1340-PIC18F1220-I/PEAN 8219671025362Item type: Assembled

Description

PIC16F84 Microchip IC
Microchip Flash microcontroller, 18-pin DIP, 16 I/O ports – 4K Flash program memory.
TECHNICAL SPECIFICATIONS
  • # Single-Word Instructions: 2048
  • 10-bit A/D (ch): 7

Technical details

Memory type Flash
Program memory (KB) 4
Supply voltage (V) 2 to 5.5
Number of pins 18
Number of I/Os 16
Flash 8/16-bit (bytes) 4 K
SRAM (bytes) 256
EEPROM (bytes) 256
ECCP (PWM) 1
EUSART yes
Timers Flash 8/16-bit 1/3
NanoWatt Features Fast Wake/Fast Control
