Cuteduino
CuteDuino is based on the ATtiny85 processor, a small chip but packed with power
SKU 1686-CUTEDUINOEAN 8219671068468Item type: Assembled, BoardArduino compatible
Description
CuteDuino is based on the ATtiny85 processor, a small chip but with a lot of power. It features an internal 16 MHz oscillator, 8 kB of Flash memory (2 kB used by the bootloader), 5 I/O including PWM and ADC, and a micro USB port for power and uploading. The bootloader on the chip allows programming via a modified version of the Arduino IDE (from DigiSpark). Particularly suitable as a low-cost solution for disposable projects, such as DIY projects, workshops, gift projects, etc. Power: 5 Vdc, dimensions (mm): 42x15x4.
Video
Technical specifications
- 5 V – 800 mA low dropout voltage regulator. Up to 15 Vdc input, thermal protection and current limiting
- Status LED
- 5 I/O
- Reset button
- Works with many Arduino libraries including the RainbowBit library
Documentation and useful links
Technical details
| Microcontroller | ATtiny85 |
|---|---|
| Flash memory | 8 kB (2 kB used for bootloader) |
| SRAM | 512 bytes |
| EEPROM | 512 bytes |
| Clock speed | 16 MHz |
| Power | via USB port 5 Vdc (external from 7 Vdc to 15 Vdc) |
| Micro USB | 1 |
