DPDT Momentary Toggle Switch (ON)-OFF-(ON)

Double-pole momentary toggle switch, rated for loads drawing up to 10 A at 250 V
DPDT Momentary Toggle Switch (ON)-OFF-(ON) - Image 1

SKU 4210-JS511GEAN 8219671011181Colour: SilverContact configuration: DPDTHole size: 12 mmLighting: NoneSwitch action: (ON)-OFF-(ON)Item type: Buttons & switches

Description

Double-pole momentary toggle switch, rated for loads drawing up to 10 A at 250 V. Type: DPDT (double pole, double throw). Push the lever towards either side contact and it springs back to the centre position as soon as you let go. Dimensions 33 x 20 x 57.7 mm. Mounting hole diameter: 12.2 mm. Screw-terminal connections.
