3-Channel Relay Board for Raspberry Pi

3-Channel Relay Board for Raspberry Pi - Image 1
3-Channel Relay Board for Raspberry Pi - Image 3
3-Channel Relay Board for Raspberry Pi - Image 4
3-Channel Relay Board for Raspberry Pi - Image 5

SKU 2850-RPIRELEBOARDEAN 8219671078184Item type: Assembled, Shields & add-ons

Description

The RPi relay board is a compact add-on for the Raspberry Pi (A+ / B+ / 2B / 3B / 3B+) with 3 high-quality relays rated for loads up to 250 VAC/5 A and 30 VDC / 5 A, one optocoupler (PC817) per input, LEDs showing relay and power status, and 3 jumpers that let you drive the relays straight from the Raspberry Pi or from another device
The RPi Relay Board turns your Raspberry Pi into a powerful controller for electrical devices. With this board you can easily turn ordinary appliances into smart devices.

Key features:

  • Universal compatibility: Standard 40PIN GPIO extension connector for Raspberry Pi, compatible with every board in the Raspberry Pi series.
  • Optocoupler isolation: Effective protection against interference from high-voltage circuits.
  • LED indicators: Show the relay status in real time.
  • Flexible relay control: Thanks to the control jumpers you are free to use the default pins or your own to drive the relays.

What is on the RPi Relay Board:

  • Raspberry Pi GPIO interface for direct connection.
  • Relay screw terminals for wiring the target devices.
  • High-quality relays for reliable switching.
  • PC817 optocoupler for safe isolation.
  • Power indicator and relay control jumpers for easy, effective customisation.

The WiKi page offers plenty of development resources, including examples in wiringPi, WebioPi, Shell, Python and bcm2835.

Documentation and useful links

Technical details

High-quality relays Load capacity up to 5A 250V AC or 5A 30V DC
Developer resources included Examples in wiringPi, WebioPi, shell, python and bcm2835 get you started quickly
LED on relay NC open, NO closed
LED off relay NC closed, NO open
Power from the Raspberry Pi
dimensions (mm) 65.15x56.21
weight 59 g
