DC/DC Step-down converter with 9V – 1A output – 3 pin

Buck step-down converter module: takes voltages from 11 to 40 V and provides a fixed 9 V output with current up to 1 A.
DC/DC Step-down converter with 9V - 1A output - 3 pin - Image 1

SKU 2846-REG1ADC9VKEAN 8219671114387Output voltage: 9 VdcItem type: AssembledConversion type: Step-down

Description

This buck step-down DC-DC converter is ideal for stepping high voltages (up to 40 V) down to 9 V efficiently. With a stable output of up to 1 A, it is perfect for powering sensors, logic modules and other 9 V circuits. The module offers overload protection, high efficiency and a compact size, which makes it suitable for embedded projects, automation and powering electronic parts. With its three terminals it is easy to fit into existing systems in place of traditional voltage regulators.
Technical features
  • Short-circuit and over-temperature protection: Yes

Technical details

Input voltage from 11 V to 40 V
Output voltage 9 V
Output current max. 1 A
Switching frequency 550 KHz
Conversion efficiency 76-90%
Overcurrent protection Yes
Operating temperature from -40°C to +85°C
Connector pitch 2.54 mm
Dimensions (mm) 22.3x10.2x6.7
Weight 2.5 grams
