Switching power supply 5V – 90W
Compact, professional-grade 90W switching power supply with a regulated 5V (18A) output. Designed for high efficiency and full protection, it is the ideal choice for a wide range of 5V-powered applications.
SKU 4125-MW10005EAN 8219671083256Output voltage: 5 VdcBench power supplies
Description
| Bench power supply using high-efficiency switching technology, with long service life and outstanding reliability. Metal enclosure, natural convection cooling, input voltage from 90 to 264 VAC, output voltage 5 volts, current 18 A, power 90 W. It features a power-on LED indicator plus short-circuit and overload protection. Switching technology gives the unit a considerably lower weight and a very high energy efficiency. |
| Technical specifications |
|
| Documentation |
Technical details
| Input voltage | 90 - 264 VAC |
|---|---|
| Inrush current | 50 A / 230 VAC (cold start) |
| Leakage current | <1 mA / 240 VAC |
| Output voltage | 5 VDC (± 1%) |
| Output voltage range | 4.5 V to 5.5 V (adjustable) |
| Output current | 18 A |
| Current range | 0 to 18 A |
| Ripple and noise (max) | 100 mVpp |
| Output power | 90 W |
| Efficiency | 86% |
| Connection | 7-way terminal block |
| Overload protection | 120-145% of rated output power |
| Dimensions (mm) | 130 (length) x 98 (width) x 31 (height) |
| Weight | 380 g |
