Wired Thermostat
Thermostat for controlling heating or air conditioning systems
SKU 8240-TP385EAN 8595563726464Item type: AssembledOther home products, Timers & thermostats
Description
Thermostat for controlling heating or air conditioning systems. It features a large backlit display with big numbers and temperature information, temperature adjustment range: from +5°C to +35°C (in 0.5°C steps), relay for controlling a resistive or inductive load, temperature measurement accuracy: approximately 1°C (at 20°C), frost protection function and low battery indication.
Possible applications: temperature control of machinery, server rooms, proofing cells, domestic use, etc.
Technical specifications
- Time programming: No, only switching the system on and off based on the set temperature
- Frost protection for the heating system: Yes
- Power supply: 2 x 1.5-volt AAA batteries (included) – Resistive load: Max. 6 A / 230 VAC
Technical details
| The package includes | the thermostat with two 1.5-volt AAA batteries and instruction manual in English |
|---|---|
| Temperature display range | from 0°C to +40°C (in 0.1°C steps) |
| Temperature adjustment range | from +5°C to +35°C (in 0.5°C steps) |
| Temperature measurement accuracy | approximately 1°C (at 20°C) |
| Inductive load | Max. 2 A / 230 VAC |
| Display backlight | white |
| Low battery warning | Yes |
| Standby consumption | <50 µA |
| Consumption with backlight | < 6 mA |
| Color | white |
| Dimensions (mm) | 130x86x35 |
| Weight | 192 grams (with batteries) |
