Wireless Thermostat

Description

System for controlling a heating or air-conditioning system. It consists of a wireless thermostat (868.35 MHz) with a large backlit display and a receiver unit capable of controlling resistive and inductive loads. The thermostat’s transmission range allows the receiver unit to be installed at a maximum distance of about 200 meters (without obstacles). The thermostat has a temperature adjustment range from +5°C to +35°C (in 0.5°C steps), features a large backlit display with large numbers and information on the set temperature, anti-frost function, and low battery indication. The receiver unit can control a maximum resistive load of 16 A / 230 VAC or inductive load of 4 A / 230 VAC, and has a button for manual/automatic control, a button to activate or deactivate the load, and an on/off switch.

Possible applications: temperature control of machinery, server rooms, proofing cells, domestic use, etc.

The package includes: the wireless thermostat with two 1.5-volt AAA batteries, the receiver unit, and an instruction manual in Italian.

Technical specifications

• Thermostat with display (transmitting unit):
  – Time programming: No, only switching the system on and off based on the set temperature.
  – Protection against freezing of the heating system: Yes
  – Standby consumption: – Consumption with backlight: – Color: white
  – Dimensions (mm): 130x86x35
  – Weight: 160 grams (with batteries)
• Receiver unit:
  – Power supply: 230 VAC – 50 Hz
  – Reception frequency: 868.35 MHz
  – Consumption: 6 watts
  – Resistive load: Max. 16 A / 230 VAC
  – Inductive load: Max. 4 A / 230 VAC
  – Color: white
  – Dimensions (mm): 86x86x28
  – Weight: 152 grams
