NEMA 17 Bipolar Stepper Motor – 2.5 A

Ideal for use with the 3DRAG printer and for any application that calls for precise angular positioning and rotation speed, such as robotics and servomechanisms.
NEMA 17 Bipolar Stepper Motor - 2.5 A - Image 1

SKU 7300-STEPMOT3DRAGEAN 8219671025775, ,

Description

Ideal for use with the 3DRAG printer and for all applications requiring precision in angular displacement and rotation speed, such as in robotics and servomechanisms.

Dimensions and Connections

Technical details

Mounting NEMA 17
Shaft diameter 5 mm
Step angle 1.8° ±5%
Number of phases 2
Rated voltage 3.1 V
Phase current 2.5 A
Resistance per phase 1.25 ohm
Inductance per phase 1.8 mH
Insulation resistance 100 Mohm min. (500 Vdc)
Holding torque 4.8 kg/cm
Rotor inertia 68 g-cm²
Dimensions 48 x 42.3 x 42.3 mm
Operating temperature -20°C to +50°C
Weight 340 g
